Digital Micro Ohm Meter
Measure the Resistance of a Device with Ease
The digital micro ohm meter will simply work great in case you wish to know the electrical resistance of a device. The product of a leading digital micro ohm meter suppliers in India, S.B.Electrotech will help you realise the formed contact resistance of a device towards the current. You can handle the device to use in the transformer industry, panel industry, cable industry, switchgear industry etc. S.B.Electrotech’s product is thus a great way to grow income for your business.
Call Now: +91 94774-23085
View More
PRODUCT GALLERY
True Four Terminal Measurement Made Easy
The DC micro ohm meter comes with the four-terminal measurement that has the functionality of electrical impedance that can separate pairs of current-carrying and voltage-sensing electrodes for doing the true measurements rather than the two-terminal sensing analysis. You can use the digital micro ohm meter manufacturers in India products for the manufacturing of strain gauge, resistance thermometers, and a lot of other components you can imagine. Try out S.B.Electrotech’s product today to avail the profit in your business now!
View More
MODELS Of DIGITAL MICRO OHM METER
- True Four Terminal Measurement.
- 3½ Digit LED / LCD Display.
- 1µΩ resolution on 2000 µΩ range.
- Stable and fast measurement.
- Regulated and Highly stable 1 Amp. Current Source.
- Test Laboratories.
- Instrumentation Table.
- Communication Cable.
- Transmission and Distribution.
- Component Manufacturer.
- College Laboratories.
- Transformer, Motors coil manufacturers.
- Current Transformer Manufacturers.
| Range | Current | Resolution | Accuracy |
| 1999 μΩ | 1A | 1 μΩ | ± 0.5 % of rdg ± 3 Digits |
| 199.9 μΩ | 1A | 0.1 mΩ | ± 0.5 % of rdg ± 3 Digits |
| 19.99 μΩ | 1A | 0.01 mΩ | ± 0.5 % of rdg ± 3 Digits |
| 1999 mΩ | 1A | 1 mΩ | ± 0.5 % of rdg ± 2 Digits |
| 19.99 Ω | 100 mA | 0.01 Ω | ± 0.5 % of rdg ± 2 Digits |
| 199.9 Ω | 10 mA | 0.1 Ω | ± 0.5 % of rdg ± 2 Digits |
| 1999 Ω | 1 mA | 1Ω | ± 0.5 % of rdg ± 2 Digits |
| 19.99 KΩ | 0.1 mA | 0.01 Ω | ± 0.5 % of rdg ± 2 Digits |
| Power Supply | 230 V AC, 50 Hz, Single Phase. | ||
- User Manual.
- Mains Power Cord.
- 1 Set of Test Leads ( 1 Meter ) with Crocodile Clip.
