High Voltage Cable Tester for Finding Cable Faults
Find the Cable Fault by a Single Machine
The machine will save you through the cable faults. It's seen that the cables are damaged due to heavy loads and unpleasant weather situations. The product does justice to these times. The service seeker should be your end goal if you want to benefit in organisation and that’s the reason the top high voltage cable tester suppliers in India have designed the product. You can take this shockproof device in a harsh climate and it will give you a smooth repair. You will know about the live wire, its failure reason, live voltage detection, and further.
Call Now: +91 94774-23085
Voltage Detection Levels for an Accurate Testing
The high voltage DC tester will serve you know the five intensity detection levels that can range from 3 kV to 33 kV. When you have this type of voltage detection level, you have more freedom to test the cable’s fault to the right extent. Being a repairman, you need to find the issues of the data cable or electrical cable that lead the electricity to the end-user.
The testing will benefit you and get you high profit in your company and will stimulate you to make the new cables for the business to business and business to consumer segments. Try the high voltage cable tester manufacturers in India products now!
| Function | Voltage Detection. |
| Voltage Ranges | 3 KV; 6 KV; 11 KV; 20 KV; 33 KV. |
| Insulation Rob | 6 meters in 4 Sections (Optional). |
| Power Supply | DC 9V, (6F22 IPC) |
| Instrument Size | 115 mm(L) X 115 mm(W) X 169 mm(H) |
| Protection Class | IP65 |
| Indicating Function | Sound and Light indicating when the detection voltage exceeds the setting voltage |
| Weight | 390 g (With Battery) |
| Operating Temperature & Humidity | -10 °C ~ +50 °C < 85% RH |
| Storage Temperature & Humidity | -15 °C ~ +55 °C < 90% RH |
| Safety Regulations | EN 61326-1, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8 |
| The Packing List | |
| Instrument | 1 Set. |
| 9 V Battery | 1 Section. |
| Color BOX | 1 Piece. |
| Instruction, Warranty | 1 Set. |
